Design render

CWRU CPU Docs

<p align="center"> <img height="500px" src="./images/riscv-architecture.png" > </p>

Credit: Patterson & Hennessy, Computer Organization and Design: RISC-V Edition

How It Works

This is an educational technical project aimed at teaching CWRU computer engineering students how to design a single-cycle RISC-V processor in Verilog. This info.md is meant to serve as pedagogical material for those also interested in learning computer architecture concepts. The deliverable will be a complete processor that executes a Fibonacci sequence using RISC-V assembly.


Pipeline (Big Picture)

The CPU has five stages that it must go through to complete a single instruction:

  1. IF / Instruction Fetch: Fetches the current cycle's instruction from memory
  2. ID/ Instruction Decode: Converts instructions into register addresses, opcodes, etc.
  3. EX / Execute: Perform operations with those opcodes/register values
  4. MEM / Memory: Writes/loads data to memory, more important for load/store instructions
  5. WB / Writeback: Writes result into the register file for next cycle, repeat

In a single-cycle design, all five stages happen within one clock period. Every component is connected combinationally from the output of instruction memory through to the writeback mux, with the only registered state being the program counter (updated on each clock edge) and the register file / data memory (written on the clock edge when their respective write enables are asserted).


RISC-V Opcode Reference

These are the standard base integer (RV32I) opcodes. The opcode field occupies bits [6:0] of every instruction.

Instruction Type opcode (binary) opcode (hex) Example Instructions
R-type 0110011 0x33 add, sub, and, or, slt
I-type (ALU) 0010011 0x13 addi, andi, ori, slti
I-type (Load) 0000011 0x03 lw, lh, lb
I-type (JALR) 1100111 0x67 jalr
S-type 0100011 0x23 sw, sh, sb
B-type 1100011 0x63 beq, bne, blt, bge
U-type (LUI) 0110111 0x37 lui
U-type (AUIPC) 0010111 0x17 auipc
J-type 1101111 0x6F jal
funct3 Reference

funct3 (bits [14:12]) disambiguates instructions that share the same opcode.

funct3 R-type (0x33) I-type ALU (0x13) Load (0x03) Store (0x23) Branch (0x63)
000 add / sub* addi lb sb beq
001 sll slli lh sh bne
010 slt slti lw
011 sltu sltiu
100 xor xori lbu blt
101 srl / sra* srli / srai* lhu bge
110 or ori sw bltu
111 and andi bgeu

* funct7[5] distinguishes these pairs: 0add / srl / srli, 1sub / sra / srai


Components

Program Counter

The program counter acts as a tracker for the CPU. Namely, what instruction are we executing right now? It is a register that holds the address of the instruction that's currently being executed. This number can be updated based on normal sequencing (+4 bytes per cycle for 4-byte instructions) or conditional branches and jumps that can happen in the code. The pins you'll need are:

  • clk: program counter needs to update on the clock, keeping it synchronized with the rest of the CPU
  • pc_in: this is a little tricky but this is the next address to execute, it may come from a branch
  • pc_out: this is the current address being executed, and pc_in will propagate on the next edge

Essentially, the program counter is just a large 32-bit flip-flop if that helps the Verilog code. As for the lack of reset pins for this program counter, it's cleaner to have a separate register in the top module that's sensitive to the reset and propagate it into the program counter, as opposed to having reset here and needing to reset the pc signal in the top module anyway.

Instruction Memory

Instruction memory is a piece of RAM that stores your instructions for the processor to execute. It may be more intuitive to think of an instruction memory as an array:

// this array would be your instruction memory
unsigned char instructions[256] ={0x00000013, 0x00000013, 0x00000013, ...};
// to access the array, you need to do some indexing
// normal cpu operation

// we have a register named curr_instr
unsigned char curr_instr;

// we use a for loop here, the counter variable
// i is just like our program counter
for (int i = 0; i < 256; i++) {
    curr_instr = instructions[i];
}

For those who are technically sharp, this isn't 100% accurate because of possible branch/jump instructions, but for 99% of cases when the CPU is running sequentially, this is a perfect parallel. The pins you'll need are:

  • pc: the output of your program counter (incrementer)
  • instr: whatever instruction needs to be executed

Hint: to instantiate an array block in Verilog, you can do this:

    wire [WIDTH-1:0] mem [0:DEPTH-1];
  • Just remember if you're updating it in a process, use reg instead
  • mem is just the assigned name, you can name it anything
  • WIDTH is how wide each word is, maybe let's say 32 bits wide
  • DEPTH is how many words can be stored at a given time in mem

You can pre-load instruction memory using $readmemh in a Verilog initial block, which reads a hex file of encoded instructions directly into your memory array:

initial begin
    $readmemh("program.hex", mem);
end
Register File

The register file is a module that, in RISC-V specification, contains 32 distinct registers. Each register itself can store a 32-bit word, which can then be used as operands within the ALU. Some design questions:

  • Does the register file need a clk signal? What are the advantages/tradeoffs of having a clocked register file?
  • We will need read and write ports for the register file. For 32 registers, how many bits do we need to identify a unique register? We will need three addresses: rd_addr1, rd_addr2, and wr_addr.

Important: In RISC-V, register x0 is hardwired to zero — writes to it must be ignored and reads from it must always return 0. Make sure your register file enforces this.

Immediate Generator

The immediate generator, like its name suggests, generates an immediate value. But what is an immediate value? Take a look at the following assembly instruction:

add x3, x1, x2

In RISC-V, there are six types of instructions: R-type, I-type, S-type, B-type, U-type, and J-type instructions. This add instruction is an R-type instruction, as it adds the contents of two registers (namely x1 and x2) and saves the result in x3. There is no immediate here. Now let's take a look at an I-type instruction:

addi x3, x1, 1

With a blank register file that will initiate all register values to 0 on power up, you would be pretty limited in what you can do with just zeroes. This "add immediate" instruction allows you to add any integer with x1, and save the result to x3.

<p align="center"> <img src="./images/riscv-format.png" height="250px" /> </p>

Source: RISC-V International, The RISC-V Instruction Set Manual, Volume I: User-Level ISA, Version 2.2.

Refer to this diagram to see how the immediates are encoded in each instruction. You can determine based on the opcodes what type of instruction it is. As for designing/writing the RTL code, treat the immediate generator as a switch case that based on the opcode, decodes the immediate value from the instruction. For simplicity, make the immediate a 32-bit logic value to keep things consistent.

All immediates must be sign-extended to 32 bits. This means replicating the most significant bit of the immediate field across all upper bits when producing the 32-bit output. In Verilog:

// Example: sign-extending a 12-bit I-type immediate
assign imm_out = {{20{instr[31]}}, instr[31:20]};
Control Unit

The control unit asserts flags that help facilitate the execute stage of the CPU. Generally, it needs to take in the opcode, funct3, and funct7 as inputs, and it outputs the following values:

  • RegWrite: are we writing the result to reg?
  • MemRead: are we reading from memory?
  • MemWrite: are we writing to memory?
  • BranchEq: is the beq condition satisfied?
  • MemToReg: are we loading from memory to reg?
  • ALUSrc: which operand are we using? (0 = rs2, 1 = immediate)
  • ALUCont: what type of ALU operation are we doing? (passed to ALU control)
  • JMP: did a jump occur?

This can be implemented using a really large switch case. Recall that we have 6 types of instructions (R, I, S, B, U, J) all with different opcodes and funct codes.

The table below summarizes what each control signal should be asserted to for each major instruction type:

Signal R-type I-type (ALU) I-type (Load) S-type B-type J-type
RegWrite 1 1 1 0 0 1
ALUSrc 0 1 1 1 0
MemRead 0 0 1 0 0 0
MemWrite 0 0 0 1 0 0
MemToReg 0 0 1 0
BranchEq 0 0 0 0 1 0
JMP 0 0 0 0 0 1
R-type

R-type (R for register) instructions are one of the common types of instructions that you will encounter in the assembly language. R-type operations always take two values from the register file, perform an operation (addition, subtraction, multiplication, division), then writes directly back to the register file.

I-type

I-type instructions are also extremely common but slightly different from R-type instructions, where the I-part stands for "immediate". The I-type instruction typically takes only one register and a user-defined constant (0-4095) as operands, making it useful for easy increments without having to explicitly reference a second register operand. Load instructions (lw, lh, lb) are also encoded as I-type: the immediate serves as a byte offset added to rs1 by the ALU to compute the memory address.

S-type

S-type (store) instructions write a register value into data memory. The destination address is computed as rs1 + imm, where the 12-bit immediate is split across two non-contiguous fields in the instruction encoding — bits [11:5] in instr[31:25] and bits [4:0] in instr[11:7]. Your immediate generator must reassemble these pieces. Common S-type instructions: sw (store word), sh (store halfword), sb (store byte).

B-type

B-type (branch) instructions conditionally redirect the program counter based on a comparison between two registers. The branch target is PC-relative: PC + imm, where imm is a signed 13-bit offset (always even, since instructions are 4-byte aligned). The immediate is also scrambled across the instruction word — refer to the encoding diagram above carefully. The ALU computes rs1 - rs2 and the zero_flag tells the control unit whether the branch condition is satisfied. Common B-type instructions: beq, bne, blt, bge.

U-type

U-type (upper immediate) instructions load a 20-bit immediate into the upper 20 bits of a destination register (bits [31:12]), zeroing the lower 12 bits. This is useful for constructing large constants in combination with an I-type instruction. For example, lui x1, 0x12345 followed by addi x1, x1, 0x678 builds the full 32-bit constant 0x12345678 in x1. The two U-type instructions are lui (Load Upper Immediate) and auipc (Add Upper Immediate to PC, useful for position-independent addressing).

J-type

J-type (jump) instructions unconditionally redirect the program counter. Like B-type, the target is PC-relative, but the immediate is 21 bits, allowing larger jumps. The return address (PC + 4) is saved into rd, enabling function calls and returns. The immediate bits are scrambled across the instruction word — be careful to reassemble them correctly in your immediate generator. The primary J-type instruction is jal (Jump and Link). Its register-indirect cousin, jalr (Jump and Link Register), is actually encoded as an I-type with opcode 0x67.

Arithmetic Logic Unit

The arithmetic logic unit (also known as the ALU) is the calculator that performs mathematical operations on your operands. The ALU accepts the following pins:

  • op1: your first operand (always rs1 from the register file)
  • op2: second operand — either rs2 (R-type) or the sign-extended immediate (I/S/B-type), selected by the ALUSrc control signal upstream
  • alu_ctrl: the specific operation to perform (add, sub, AND, OR, SLT, etc.)
  • res: the 32-bit result of the operation
  • zero_flag: asserted when res == 0; used by the control unit to evaluate branch conditions

The alu_ctrl lines are typically driven by a small sub-module called the ALU Control Unit, which takes ALUCont (from the main control unit) plus funct3 and funct7 to determine the exact operation. For example, both add and sub share the R-type opcode 0x33 — it is funct7[5] that distinguishes them.

alu_ctrl Operation Used by
0000 AND and, andi
0001 OR or, ori
0010 ADD add, addi, lw, sw
0110 SUB sub, beq (zero check)
0111 Set Less Than (SLT) slt, slti
1100 NOR (less common)
1101 XOR xor, xori
1110 Shift Left Logical sll, slli
1111 Shift Right Logical srl, srli

Note: the alu_ctrl encoding above is one common convention — what matters is internal consistency between your ALU and ALU control unit.

A minimal Verilog skeleton for the ALU:

module alu (
    input  [31:0] op1,
    input  [31:0] op2,
    input  [3:0]  alu_ctrl,
    output reg [31:0] res,
    output zero_flag
);
    always @(*) begin
        case (alu_ctrl)
            4'b0000: res = op1 & op2;          // AND
            4'b0001: res = op1 | op2;          // OR
            4'b0010: res = op1 + op2;          // ADD
            4'b0110: res = op1 - op2;          // SUB
            4'b0111: res = (op1 < op2) ? 1 : 0; // SLT
            4'b1101: res = op1 ^ op2;          // XOR
            4'b1110: res = op1 << op2[4:0];    // SLL
            4'b1111: res = op1 >> op2[4:0];    // SRL
            default: res = 32'b0;
        endcase
    end
    assign zero_flag = (res == 32'b0);
endmodule
Data Memory

The data memory acts as a secondary RAM that stores runtime data (not instructions). Specifically, STORE instructions write data from the register file into data memory, and LOAD instructions read data back from memory into the register file.

The pins you'll need are:

  • clk: data memory writes are synchronous — they happen on the clock edge
  • addr: the memory address to read from or write to (comes from the ALU result)
  • wr_data: the data to be written (comes from rs2 in the register file)
  • MemRead: control signal asserted for load instructions (lw)
  • MemWrite: control signal asserted for store instructions (sw)
  • rd_data: the data read out of memory (routed to the writeback mux)

A few design notes:

  • Address alignment: RISC-V word addresses are 4-byte aligned. The ALU computes the full byte address, so index into your word-addressed memory array using addr[N:2] (dropping the two LSBs).
  • Read vs. Write: Writes must be clocked (registered) so data is only committed on the clock edge. Reads can be combinational in a single-cycle design so the data is available immediately within the same cycle.
  • MemToReg mux: The MemToReg control signal selects whether the writeback value into the register file comes from the ALU result (MemToReg = 0) or from rd_data (MemToReg = 1). This 2:1 mux lives between data memory and the register file write port, typically in your top-level datapath.
module data_memory (
    input         clk,
    input  [31:0] addr,
    input  [31:0] wr_data,
    input         MemRead,
    input         MemWrite,
    output [31:0] rd_data
);
    reg [31:0] mem [0:255];  // 256 words of data memory

    always @(posedge clk) begin
        if (MemWrite)
            mem[addr[9:2]] <= wr_data;  // word-aligned write
    end

    assign rd_data = MemRead ? mem[addr[9:2]] : 32'b0;
endmodule

Top-Level Datapath

With all components implemented, the top-level module wires them together. The signal flow for a typical R-type instruction looks like this:

PC → Instruction Memory → [opcode/rs1/rs2/rd/funct3/funct7]
                              ↓              ↓
                        Control Unit    Register File (read rs1, rs2)
                              ↓              ↓
                         ALUSrc mux ← rs2 or Immediate Generator
                              ↓
                             ALU → res → MemToReg mux → Register File (write rd)
                                          ↑
                                     Data Memory (if Load)

For branch instructions, the ALU zero_flag is AND-ed with BranchEq to decide whether pc_in comes from PC + 4 (sequential) or PC + imm (branch taken). For jump instructions, pc_in is driven directly to PC + imm when JMP is asserted.


Target Program: Fibonacci Sequence

The goal of this project is to execute the following Fibonacci sequence program in RISC-V assembly. Use this as your integration test — if your CPU correctly drives the seven-segment display through all Fibonacci values, all five pipeline stages and all major instruction types are working.

# Fibonacci sequence in RISC-V assembly
# x1 = F(n-2), x2 = F(n-1), x3 = F(n), x10 = loop counter

    addi x1, x0, 0       # F(0) = 0
    addi x2, x0, 1       # F(1) = 1
    addi x10, x0, 10     # compute 10 terms

loop:
    add  x3, x1, x2      # F(n) = F(n-1) + F(n-2)
    add  x1, x0, x2      # x1 = old x2
    add  x2, x0, x3      # x2 = new F(n)
    sw   x3, 0(x0)       # store result to data memory (addr 0)
    addi x10, x10, -1    # decrement counter
    bne  x10, x0, loop   # if counter != 0, loop

This program exercises addi (I-type), add (R-type), sw (S-type), and bne (B-type) — a solid cross-section of the instruction set that validates your control unit, ALU, register file, data memory, and branch logic all at once.


How to Test

Simulation (Icarus Verilog or Vivado XSim)
  1. Pre-load instruction memory using $readmemh("fibonacci.hex", mem) in an initial block inside your instruction memory module.
  2. Write a testbench that instantiates your top-level CPU, drives clk, and asserts reset for the first few cycles.
  3. Use $monitor or $dumpvars to observe register file contents and data memory writes over time.
  4. Verify that after 10 loop iterations, the sequence 0, 1, 1, 2, 3, 5, 8, 13, 21, 34 appears at memory address 0 across successive cycles.
On Hardware (Seven-Segment Display)

The CPU will drive a seven-segment display showing each Fibonacci value in sequence. Confirm that the display cycles through the correct values without freezing or producing garbage output. Common failure modes to watch for:

  • Display stuck on one value → branch logic not redirecting the PC correctly
  • Display shows wrong values → ALU or immediate generator bug
  • Display cycles too fast / too slow → clock domain issue at the top level

External Hardware

There's no external hardware needed to run this ASIC! It will run a Fibonacci sequence on the seven-segment display using the assembly instructions above.
