195 SPI-connected PWM generator
195 : SPI-connected PWM generator
- Author: Damir G
- Description: SPI-connected PWM generator featuring 8 outputs with 2 independent generators and 4 total PWM channels
- GitHub repository
- Open in 3D viewer
- Open in Tiny Tapeout Explorer
- Clock: 10000000 Hz
How it works
Will add later
How to test
Will add later
External hardware
Will add later
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | SCLK | OUT_0 | |
| 1 | COPI | OUT_1 | |
| 2 | nCS | OUT_2 | |
| 3 | OUT_3 | ||
| 4 | OUT_4 | ||
| 5 | OUT_5 | ||
| 6 | OUT_6 | ||
| 7 | OUT_7 | CIPO |
