934 One-tile ADC
934 : One-tile ADC
- Author: Daniel S
- Description: This is the stand-in for my ADC ASIC design. Idea is to use a clamped ±3V sinudoid on an input pin which will be digitsed with this circuit.
- GitHub repository
- Open in 3D viewer
- Open in VGA Playground
- Clock: 25175000 Hz
How it works
This tile uses a DSP block to do this. (I'm not actually sure yet, just using this as a placeholder).
How to test
Apply a ±3V analogue signal of any shape to input pin 1. Enable input pin 2 to begin digitisation.
External hardware
A function generator is useful for testing.
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | R1 | ||
| 1 | G1 | ||
| 2 | B1 | ||
| 3 | VSync | ||
| 4 | R0 | ||
| 5 | G0 | ||
| 6 | B0 | ||
| 7 | HSync |
