136 Osian Tiny Tapeout
136 : Osian Tiny Tapeout
- Author: Osian Edwards
- Description: Simple logic gates to test
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 0 Hz
How it works
Explain how your project works
All input at 0, gives a 0 output, G being the only output that is 0. A-F is 1.
How to test
Explain how to use your project
Put all input to 0, to get an O or 0 digit.
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | input0 | outA | |
| 1 | input1 | outB | |
| 2 | input2 | outC | |
| 3 | input3 | outD | |
| 4 | outE | ||
| 5 | outF | ||
| 6 | outG | ||
| 7 |
