591 Tiny Tapeout Test
591 : Tiny Tapeout Test
- Author: Nayli Azli
- Description: Test logic gates to create first letter of my name
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 0 Hz
How it works
AND, OR and NOT gates are connected to input b, input c and input a.
How to test
Set the inputs and check the outputs match with the expected results.
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | input a | output not | |
| 1 | input b | output and | |
| 2 | input c | output or | |
| 3 | |||
| 4 | |||
| 5 | |||
| 6 | |||
| 7 |
