424 CS First Wokwi design
424 : CS First Wokwi design
- Author: Cameron Spearing
- Description: Displays 6 by default and displays 7 when button is pressed
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 100000 Hz
How it works
Displays the number 6 on startup. When the "Step" button is held, it changes to display the number 7.
How to test
Hold down the "Step" button.
External hardware
NA
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | LOW input feeds into MUX | HIGH when MUX HIGH OR LOW | |
| 1 | HIGH input feeds into MUX | HIGH when MUX LOW | |
| 2 | HIGH when MUX HIGH OR LOW | ||
| 3 | HIGH when MUX HIGH | ||
| 4 | HIGH when MUX HIGH | ||
| 5 | HIGH when MUX HIGH | ||
| 6 | HIGH when MUX HIGH | ||
| 7 |
