684 Tiny Tapeout: Buenos días Mundo!

684 : Tiny Tapeout: Buenos días Mundo!

The project enables the user to test the effect of different logic gates

Turn different switches on/off, attempting to get a specific outcome. Some of the inputs and outputs are interconnected between gates.

Switches and single number LED display.

#	Input	Output
0	Logic input	Logic output
1	Logic input	Logic output
2	Logic input	Logic output
3	Logic input	Logic output
4	Logic input	Logic output
5	Logic input	Logic output
6	Logic input	Logic output
7	Logic input	Logic output
