746 Workshop Day
746 : Workshop Day
- Author: arnonym
- Description: just a very basic circuit
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 1 Hz
How it works
Switches the output number form 0 to 1 on the segment display
How to test
Dont use it, it's just for pipeline testing
External hardware
Segment display
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | in0 | out0 | |
| 1 | in1 | out1 | |
| 2 | out2 | ||
| 3 | out3 | ||
| 4 | out4 | ||
| 5 | out5 | ||
| 6 | out6 | ||
| 7 | out7 |
