209 test
209 : test
- Author: Peter von Kürten
- Description: test AND
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 10 Hz
How it works
AND and clock
clc= out7
How to test
Input A & B Output
00 0
01 0
10 0
11 1
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | In0 | And | |
| 1 | In1 | ||
| 2 | In2 | ||
| 3 | |||
| 4 | |||
| 5 | |||
| 6 | |||
| 7 | clc |
