750 FirstTapeOut2

750 : FirstTapeOut2

inputs 0 and 1 are connected to the red and. The outout of the and is connected to the outputs 0,2,3,5,6.

inputs 2 and 3 are connected to an another and. Theo output of this and is connected to the output 4.

Set only first to inputs to 1, you should see the number five.

Then set onyl inputs #2, #3 to one, the lower left segment should set to light.

List external hardware used in your project (e.g. PMOD, LED display, etc), if any

#	Input	Output
0	input red and	output red and
1	input red and
2	input and	output red and
3	input and	output red and
4		output and
5		output red and
6		output red and
7
