705 Tiny Tapeout chip
705 : Tiny Tapeout chip
- Author: Birk Weber Kock
- Description: A working chip design
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 1 Hz
How it works
Taking a 4 bit input and decoding it to a decmal number displayed on a 7 segment display
How to test
change input 0-3 to test it.
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | input a | ||
| 1 | input b | ||
| 2 | |||
| 3 | |||
| 4 | |||
| 5 | |||
| 6 | |||
| 7 |
