653 Tiny Tapeout Amaury Basic test
653 : Tiny Tapeout Amaury Basic test
- Author: Amaury
- Description: Je kiffe l'électro :smiley_rock:
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 10000 Hz
How it works
It's just a copy of the initial template with slight modifications
How to test
Just switch buttons
External hardware
Buttons and 7 segment display
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | IN0 | OUT0 | |
| 1 | IN1 | OUT1 | |
| 2 | IN2 | OUT2 | |
| 3 | IN3 | OUT3 | |
| 4 | IN4 | OUT4 | |
| 5 | IN5 | OUT5 | |
| 6 | IN6 | OUT6 | |
| 7 | IN7 | OUT7 |
